Main Features

● 1200 lines/mm holographic blazed grating and high quality silicon photocell ensure the high accuracy and precision
● 7 inch color touch capacitive screen, excellent human-computer interface
● The concentration measurement methods include linear regression method and coefficient method
● functions of dynamic time scanning, time setting and multiple language
● memory can store 30 concentration curves
● Flanged base deuterium lamp is easy to replace
● Automatic adjustment of 0%(T) and 100%(T)
● Automatic light gate technology, no blackbody, protect the silicon photocell

Specificatons

Optical path type: Single beam

Monochromator type: Czerny-Turner

Focus Distance: 160mm

Detector: Import Silicon Photocell

Display: 7 inch color touch capacitive screen

Wavelength setting: Automatic

Wavelength range: 200-1000nm

Wavelength accuracy: ± 2nm

Wavelength repeatability: ≤ 1nm

Spectrum bandwidth: 2nm

Stray light: ≤ 0.1% T(220nm NaI, 360nm NaNo2)

Photometric range: 0.0-200.0% (T) -0.301-3.000 (A) 0.000-9999 (C)

Photometric accuracy: ± 0.5% T ±0.004Abs（0 – 0.5A） ±0.008Abs（0.5 -1A）

Photometric range: ≤ 0.2% T 0.002Abs（0 – 0.5A） 0.004Abs（0.5 – 1 A）

Edge Noise: ≤ 0.2% T

Pinte: Built-in thermal printer

Cuvette holder size: 10mm

Communication port: USB

Power: AC220V±10%, 50Hz±1Hz, 120W

N.W.: 15kg

G.W.: 18kg

Package size: 560x480x290mm 0.078M3

Standrad Accessories

● Quartz cuvette 10mm 2 pcs
● UV WIN7 operating software 1

Optional Accessories

● Cuvette holder 50mm
● Other size cuvette
