Applicable test methods (per <0931>):
Method 1 (Basket Method)
Method 2 (Paddle Method)
Method 3 (Small Vessel Method)
Method 4 (Paddle-over-Disk Method)
Method 5 (Rotating Cylinder Method)
Product Features
Operating system with account/password management, permission management, data management, audit trail, data backup functions, and test record output (print/USB).
Common sample information management for easy retrieval and use.
High-precision real-time constant temperature control with dual over-temperature protection and temperature calibration functions.
Built-in scheduled heating function, allowing users to set a specific time for the system to start heating.
Manual synchronous dosing function.
Automatic centering of dissolution vessels and stirrers.
Sealed anti-evaporation cover design to effectively reduce medium evaporation.
Convenient water circulation pipeline design with professional medical-grade quick connectors.
Free IQ/OQ validation documents provided.
Technical Parameters
Item RCZ-8N Specification
Dissolution Channels 8 channels
Paddle Swing Amplitude ≤ 0.5 mm
Basket Swing Amplitude ≤ 1.0 mm
Shaft-to-Vessel Axis Deviation ≤ 1.0 mm
Speed Setting Range 10 – 300 RPM
Speed Stability Error ≤ ±1%
Temperature Control Range Ambient to 45.0 °C
Temperature Resolution 0.1 °C
Temperature Control Accuracy ≤ ±0.3 °C
Maximum Operating Time 999 hours 59 minutes 59 seconds
Power Supply AC220V ±10%, 50Hz
