Product Features
Display of test data and curves in real time, monitoring the whole process of testing.
Provides automatic printing set function, the user can operate more simple and convenient；
Water Based test (WH) for Hydrophobic Filter: using purified water as test liquid instead of IPA and Ethanol, thus it can avoid trace quantity of ethanol or IPA contamination when testing filters；
The instrument can store 500 history record and curve.
Application Area

Pharmaceutical industry

Medical device industry

Food and beverage industry

Environmental protection industry
Technical Parameter
Detailed Parameters
◆ Power Supply100-240V AC, 50/60Hz；120W◆ Operation pressure100-8000mbar (115psi)◆ Unitmbar◆ Operation ConditionAmbient Temperature：+5℃ ~ +40℃；Relative Humidity：10-80%◆ Operation ConditionAmbient Temperature：+5℃ ~ +40℃；Relative Humidity：10-80%◆ Dimension（mm）400（Depth）*240（Width）*270（Height1）*220(Height2)◆ Test FunctionManual Bubble point Test；Basic Bubble Point Test；Extensive Bubble Point Test；Diffusion Flow Test；Water Immersion Test；◆ Test AccuracyUpstream Volume：± 4%；Bubble Point：≤± 50mbar ；Diffusion Flow Test：≤± 4% ；Water Immersion Test：≤± 0.05ml◆ Test ScopeBubble Point ：590-6900mbar Diffusion Flow Speed：1-180ml/min WI：0.01-30ml/min◆ Applied RangeSymmetric and asymmetric membrane test, needle filter, filter bag, flat filter, filter cartridge (3 core within 20 inches)；◆ Print FunctionBuilt-in printer；◆ Historical Records500 sets；◆ Display Screen5.7″TFT，Single color；◆ Serials portRS232；◆ LanguageChinese or English；◆ Work ModeOnline/Offline；◆ Applicable EnvironmentAbove D level；◆ Weight6.5KG
