Features
Aluminum shell, large space draft shield
LCD with white backlight & black font
Tare function
Language: Chinese / English
Overload alarm, level indicator
Interface: RS232, optional printer
Date / time / sample quantity / yarn blend code setting
Auto store 100 data records, support delete & continue
Unit conversion: oz, Tex, Nm, Ne, D, g, m², oz/yd²
Statistics & print: each weighing value, max, min, average (AV), uneven rate (CV)
Specifications
Item Parameter
Model JA203SD
Capacity 210 g
Readability 0.001 g
Min Weighing 0.004 g
Repeatability ±0.002 g
Linearity ±0.003 g
Pan Size Φ90 mm
Operating Temp 5–25 °C
Interface RS232
Draft Shield Size 175×165×230 mm
Packing Size 490×335×485 mm
Calibration Weight 200 g
Gross Weight 9 kg
