Product Features
1. Meet the 2020 edition of the Chinese Pharmacopoeia, which can directly detect the size and quantity of insoluble particles in injection, sterile powder and pharmaceutical packaging materials.
2. Adopt high-performance imported laser light source and compensation circuit to ensure the test accuracy of various colorless and colored samples. It can directly detect non-electrolyte inspection products
Imported high-pressure injection pump sampling system is adopted, which can be set according to the sampling volume of the tested sample species, with high sampling accuracy, meeting the detection requirements of high-viscosity inspection products, and being independent of geographical location and other factors, and meeting the use of different altitudes Claim;
The sampling slit and pipeline adopt imported 316L and imported PTFE materials, which can directly detect special solutions such as organic solvents and oil bases;
According to the demand of sample injection volume, different high pressure injection systems can be replaced;
There is a pharmacopoeia standard large infusion test, and the number of tests can be set arbitrarily;
There is a special test program for small-volume injections (small injections), which can be injected according to the specifications of small injections, and automatically converted into the size and quantity of particles in the container after the test is completed, which meets the “Chinese Pharmacopoeia” and international general requirements
Adopting propeller glass stirrer, the uniform speed can be adjusted, and the stirring speed can be controlled at any time to ensure the uniformity of the particles in the container. Improve data accuracy
Color touch screen operation: Chinese input, easy and quick operation, powerful function. Multi-channel test data can be displayed at the same time;
Equipped with sample name input and automatic storage, convenient and quick operation
There is also a data storage function, which can store a large amount of test data for easy query;
Automatic data processing and multiple printing modes to meet different printing needs;
It can be connected to a computer and has the function of automatic data transmission; it can be connected to the laboratory operating platform for management, and dedicated data analysis software for data storage and statistics
The model with “S” is the audit trail version (including software, without computer);
Can provide stand-alone version of 3Q certification documents and information;
Application Area

Pharmaceutical industry

Medical device industry

Food and beverage industry

Environmental protection industry
Product Content

Model

NBC-26

NBC-26S

NBC-28

JWG-28S

NBC-36

NBC-36S

Aisle

≥5μm, ≥8μm, ≥10μm, ≥12μm, ≥25μm, ≥100μm (channels can be set arbitrarily according to user needs)

≥2μm, ≥5μm, ≥8μm, ≥10μm, ≥12μm, ≥20μm, ≥25μm, ≥100μm (channels can be set arbitrarily according to user needs)

≥2μm, ≥3μm, ≥4μm, ≥5μm, ≥6μm, ≥8μm, ≥10μm, ≥12μm, ≥15μm, ≥18μm, ≥20μm, ≥22μm ≥25μm, ≥35μm, ≥50μm, ≥100μm, (according to user Need to set the channel arbitrarily)

Test Range

1～500μm
