GENERAL FEATURES

Color High contrast LCD touchscreen, 7.0 inches.
Volumetric KF Titration.
Support oven sampling method, to meet the gas, solid, liquid in the constant moisture, trace moisture measurement.
Volumetric Karl Fischer Titration

Auto Titration Method, KF Titer Determination Method, Oven Titration Method and Oven Blank Titration Method.
The solvent manager adopts anti-leakage liquid and anti-pour design of waste liquid bottle, supports to fill titrant, drain solution, feed solvent, mix titrant and clean burette, ensure safe handling of Karl Fischer chemicals.
Data management

Auto/manual drift adjust ensures accurate results.
Selectable units including μg, mg, %, ppm, mg/L and μg/mL.
User password management.
Store up to 200 titration data sets (GLP-compliant).
RS-232 communication for print and the print format can be alternate.
USB communication for PC software.
USB drive for data export with CSV format.
Optional GMP software to implement GMP management functions (compliant with FDA 21 CFR Part 11 ).
Includes

Solvent manager
10mL burette
Volumetric vessel
Measuring electrode

Specifications

Model

KFT-41V

Principle

Karl Fischer Volumetric Titration

Water

Range

100 μg～250.0mg

Resolution

1μg

Unit

μg, mg, %, ppm, μg/L, mg/L

Repeatability

≤0.5%

mV Range

(0~2000)mV

mV Resolution

0.1mV

Polarization Current Range

±3%

Polarization Current Accuracy

±2.5%/30min

Power Supply

AC100-240V, 47-63Hz

Dimensions

240mm×370mm×270mm

Net Weight

About 4kg
