GENERAL FEATURE

High resolution LCD display, 5.7 inches.
860nm LED light Source meets ISO 7027 requirement, consistent light source for higher accuracy.
Nephelometric principle or Ratio principle.
860nm LED light Source: Auto ranging from 0~500 NTU.
Selectable turbidity units, including the NTU, FNU and EBC.
Multi-reading feature allows continuous reading, average reading and auto reading.
Zero calibration and 1-5 points calibration using Formazin standards (2, 20, 50, 200, 500 NTU).
The calibration data allows to set back to default data.
Data capacity of up to 1000 sets (GLP-compliant), including user ID, data and time.
Support for RS-232 communication for print.
Includes

5 pcs Turbidity vials
Turbidity Calibration Solution(20/200/500NTU)
PRODUCT SPECIFICATIONS

Specifications

Model

TU500

Light source

860nm LED

Measuring Unit

Range

(0.00～9.99)NTU,

(10.0～99.9)NTU,

(100～500)NTU

Resolution

0.01NTU, 0.1NTU, 1NTU

Accuracy

±2% of reading+0.02NTU

Repeatability

≤0.5%

Fluctuation

±0.5% FS/30min

General

Power Supply

AC Adapter(Input:100-240V AC; Output: 24V DC)

Dimensions

300×200×88 mm

Net Weight

About 1.5 kg
