The air suction flow rate of FX-100ST is 100 L/min. Each collection cycle can collect up to 9999 liters. This performance enables sampling to be carried out under strict requirements for monitoring sterile and clean rooms. The impact speed (the speed at which microorganisms in the air impact the surface of agar) is approximately 10 m/s, equivalent to level 5 of the Andersen sampler.
Note: FX-100ST reference standard: ISO 14698-1/2, GMP, GB16293-2010
The sampling speed is 100L/min ±2.5%, and the diameter of the culture dish used is 90-100mm.
Basic Principle
The FX-100ST is a high-performance instrument. It utilizes the principle of Andersen air sampler to extract air through a multi hole cover (465*0.6mm), and microorganisms in the airflow collide with the surface of the agar medium attached to the standard culture dish. After completing the sampling cycle, culture the dish under suitable conditions and then determine the total number of colonies.
Product Features
Suitable for standard plates with a diameter of 90-100mm.
With built in flow calibration function and temperature & humidity calibration function (required to be used with a planktonic bacteria calibration instrument which is an optional choice).
External Bluetooth printer that can print data information time, date, temperature and humidty, sampling volume).
Adjustable sampling head support clip to fit the size difference of different plates (90-100mm).
Can be connected to a 100/240V, 50-60Hz working power supply for operation, or only use batteries for operation.
The sampling volume can be set to any value between1-9999L.
Fully automatic sampling accuracy calibration to avoid manual operation errors.
Sampling flow rate 100L/min ±2.5%
Sampling delay 0-255s adjustable
Sampling volume 0-99999L adjustable
Impact rate 10.8m/s
Sampling head material Anodized aluminum oxide, suitable for most disinfection methods
Battery using time More than 5 hours
Overall dimension LWH 120120175mm
Weight 2.1Kg
