Product Features
Operating system with account/password management, permission management, data management, audit trail, data backup functions, and test record output (print/USB).
Common sample information management for easy retrieval and use.
High-precision real-time constant temperature control with dual over-temperature protection and temperature calibration functions.
Built-in scheduled heating function, allowing users to set a specific time for the system to start heating.
Convenient water circulation pipeline design with professional medical-grade quick connectors.
Free IQ/OQ validation documents provided.
Technical Parameters
Item LB-3D Specification
Disintegration Baskets 3 groups (6 tubes total)
Basket Lift Frequency 25 – 35 cycles/min
Basket Lift Amplitude 55 ± 1.0 mm
Minimum Distance from Screen to Vessel Bottom 25 ± 2.0 mm
Screen Mesh Size Standard: 2.0 mm; Optional: 0.42 mm, 0.71 mm, 1.0 mm
Temperature Control Range Ambient to 45.0 °C
Temperature Resolution 0.1 °C
Temperature Control Accuracy ≤ ±0.3 °C
Maximum Operating Time 999 hours 59 minutes 59 seconds
Power Supply AC220V ±10%, 50Hz
