Product Features
Operating system with account/password management, permission management, data management, audit trail, data backup functions, and test record output (print/USB).
Common sample information management for easy retrieval and use.
Automatic recording, statistics, and analysis of measured values.
High-precision load cell for reliable measurement accuracy.
Fast testing speed: as short as 15 seconds per tablet.
Continuous testing of up to 1000 tablets, with user-adjustable test intervals.
Visual window above the test chamber for clear, direct observation of each test process.
Touchscreen human-machine interface for convenient operation.
DC 12V operating voltage with a globally compatible power adapter for safety and convenience.
Free IQ/OQ validation documents provided.
Technical Parameters
Item YPD-350N Specification
Hardness Measurement Range 10 – 350 N
Hardness Resolution 0.01 N
Hardness Accuracy ±1.5% ±1 digit
Units N / kg / kgf (selectable)
Measurement Mode Single tablet / Continuous multi-tablet (max. 1000 tablets)
Diameter Measurement Range 2 – 25 mm
Diameter Resolution 0.1 mm
Diameter Accuracy ±0.1 mm
Power Supply DC12V, 3.0A
