Features
Internal auto calibration (FA‑EN)
Electromagnetic force sensor
LCD (white back light with black font)
Tare function / Counting / Unit conversion
Sensitivity / Speed set / Percentage
Accumulation function / Peak holding / Upper and lower set
Dynamic weighing / Net and Gross / Clock function (Option)
Print function (Baud rate setting, Continuous communication or press communication)
Calibration time setting
Overload alarm / Fault alarm / Level indicator
Option: USB / Printer
Specifications
External calibration: FA1004E, FA1104E, FA1204E, FA2004E, FA2104E, FA2204E
Internal calibration: FA1004EN, FA1104EN, FA1204EN, FA2004EN, FA2104EN, FA2204EN
Capacity: 100g, 110g, 120g, 200g, 210g, 220g
Readability: 0.0001g
Min weighing: 0.0004g
Stable Time: ≤3s
Display: LCD (white back light with black font)
Pan size: Φ80mm (Standard), Φ90mm (Option)
Operation temp: 5‑35°C
Repeatability: ±0.0002g
Linearity: ±0.0003g
Dimension: 305210305mm
Draft shield size: 175165200mm (Inner diameter)
LCD Size: 9624mm
Cal.weight: E‑External calibration / EN‑Internal calibration
Interface: RS232 (Standard), USB/Printer(Option)
Packing size: 425310*410mm
G. weight: 6.0kg
Power: 100‑240V 50/60Hz
