Product Features
It has the functions of electronic signature and user classification management
It can carry on single-point or multi-point linear calibration, to ensure that the instrument has the detection accuracy of each range interval in stability
Instrument adopts the screw linear guide motor design, so that the operation just on a touch screen can complete the whole test process；
Temperature probe adopts double refrigeration system, with a short pre-cooling time, fast detection speed,to facilitate continuous detection；
It can simultaneously display the osmotic pressure molar concentration value, the freezing point value and the molar concentration ratio；
The cooling system adopts the athermal transfer fluid design, to exempt from frequent maintenance;
Application Area

Pharmaceutical industry

Medical device industry

Food and beverage industry

Environmental protection industry
Technical Parameter
Detailed Parameters
◆ Measurement range0～2000 mOsmol◆ Sample amount100μl◆ Testing duration≤3min◆ Pre-cooling time≤3min◆ Measurement error≤1%◆ Repeatability≤1%◆ Linearity≤1%◆ Environment temperature0～30℃ Recommended for 15～25℃◆ Environment temperature≤60%◆ Power supply220V～ 50Hz 150VA◆ Dimensions223*134*360mm◆ Weight17kg◆ Resolution ratio0.1
