Product Features
77 inch color screen, english interface, easy operation
It can carry on single-point or multi-point （31 points)linear calibration, to ensure that the instrument has the detection accuracy of each range interval in stability
Suitable level management, password login, electronic singature ,compliance FDA 21PART 11
With audit trail,can record more key operation logs,as login people,test method and so on, compliance data integrity requirements
Adopt double cooling system,short pre cool time ,fast test speed
Less test sample quantity,can compliance different indutry area requirements
It can simultaneously display the osmotic pressure molar concentration value, the freezing point value and the molar concentration ratio；
The cooling system adopts the athermal transfer fluid design, to exempt from frequent maintenance;
Application Area

Pharmaceutical industry

Medical device industry

Food and beverage industry

Environmental protection industry
Technical Parameter
Detailed Parameters
◆ Measurement range0～3000 mOsmol◆ Sample amount100μl◆ Testing duration≤3min◆ Pre-cooling time≤3min◆ Measurement error≤1%◆ Repeatability≤1%◆ Linearity≤1%◆ Environment temperature0～30℃ Recommended for 15～25℃◆ Environment temperature≤60%◆ Power supply220V～ 50Hz 150VA◆ Dimensions340*300*400mm◆ Weight17kg
