[Product Advantages]

1. Compatible with 6/8/10/12-position sample rotor.

2. Imported contactless IR sensor and pressure sensor, real-time display the temperature and pressure of sample solution (NOT Vessel Wall) in each vessel and show T&P scanning curve.

3. No consumables, e.g. bursting disk, sealing cup, etc. lower maintenance cost.

4. Equip with smart 7 inches touch screen, user-friendly UI.

5. Pre-installed multiple international application methods. Users can also edit, modify and delete the methods.

6. Equip with 316L stainless explosion-proof cavity, coated with multi-layer anti-corrosive and heat resisting coatings, which greatly prolongs its service life and ensure the safety of operation.

7. High power turbulent air cooling design makes fast cooling.

8. Professional electromagnetic protection design, compatible with high-level microwave leakage protection standards.

[Technical Specification]

Model

MWD-610-T6

MWD-610-T8

MWD-610-T10

MWD-610-T12

Vessel Quantity

6

8

10

12

TemperatureMonitoring

Contactless IR Sensor Temperature Monitoring

Each Vessel Temperature Controlled

Temperature Controlling Range: 50-400℃

Max. Working Temperature: 250℃

Temperature Accuracy: ±0.1℃

PressureMonitoring

Contactless Sensor Pressure monitoring

Each Vessel Pressure Controlled

Pressure Controlling Range: 0-15MPa

Max. Working Pressure: 6Mpa

Pressure Accuracy: ±0.01MPa

Vessel Volume

100mL

Sample Vessel Material

Imported TFM

Protection VesselMaterial

PEEK+Glass Fiber

Display

7 inches ColorTouch Screen

Rotation

One Direction 360° continuous rotating

Microwave Cavity

316L stainless steel cavitywith corrosion-proof coating

Microwave Power

0-1000W (Adjustable)

Microwave Leakage

<5mW/cm2

Air Exhaust

High power corrosion-proof air blower

Power

AC 220V±10%, 10A, 50/60Hz
