MWD-800 Microwave Digestion System
[Product advantages]
1. Up to 40 Vessels, suitable for batch experiment.
2. Special Designed Sample Digestion Vessel
The auto vent and self-resealing design ensures digestion vessels can automatically release pressure and instantly reseal when a sudden over-pressure situation occurs. It reduces waste of batch samples and also avoids vessel damage.
3. Contactless Temperature and Pressure Monitoring System
The imported contactless IR sensor can measure the real-time temperature of sample solution (NOT Vessel Wall) in each digestion vessel. Meanwhile, the contactless pressure sensor can monitor the real-time pressure of each vessel. It avoids sample cross-contamination, and the real-time temperature and pressure value in each vessel are displayed during the whole digestion process and enables a clear check of digestion condition.
4. Large Storage Capacity
Up to 255 kinds of method programs can be edited and saved, each method program can set with max. 10 steps and parameters (temperature, pressure, time, microwave power).
5. Safety Protection System
The double locked security door, the real-time temperature and pressure monitoring system, the auto adjustment of over-pressure and over-temperature system and the abnormal sound monitoring ensure that a highly safe operation environment.
[Technical Specification]
Model
MWD-800
Vessel Quantity
40
TemperatureMonitoring
Contactless IR Sensor Temperature Monitoring
Each Vessel Temperature Controlled
Temperature Controlling Range: 50-400℃
Max. Working Temperature: 250℃
Temperature Accuracy: ±0.1℃
PressureMonitoring
Contactless Sensor Pressure monitoring
Each Vessel Pressure Controlled
Pressure Controlling Range: 0-15MPa
Max. Working Pressure: 6Mpa
Pressure Accuracy: ±0.01MPa
Vessel Volume
50mL
Sample Vessel Material
Imported TFM
Protection VesselMaterial
PEEK+Glass Fiber
Display
7inchesColor Touch Screen
Rotation
One Direction 360° continuous rotating
Microwave Cavity
316L stainless steel cavitywith corrosion-proof coating
Microwave Power
0-3000W (Adjustable)
Microwave Leakage
<5mW/cm2
Air Exhaust
High power corrosion-proof air blower
Power
AC 220V±10%, 10A, 50/60Hz
