Product Features
Comply with USP <1207>, ASTM F2338 standards and FDA standards
Semi-automatic detection, suitable for small batch and multi-variety testing ；
Non-destructive non-destructive testing, high accuracy, repeatability, sensitivity；
The instrument is used for vacuum pressure ,pressure decay difference detection；
The leak rate can be automatically converted into defect aperture μm；
Database storage of test results for easy quality management；
Database storage of test results for easy quality management；
Touch-type man-machine interface, simple and quick operation: after setting/selecting the test program, only need to manually put in/take out the test sample
Application Area

Pharmaceutical industry

Medical device industry

Food and beverage industry

Environmental protection industry
Technical Parameter
Detailed Parameters
◆ Differential pressure sensor±2kpa, error≤0.5%F.S◆ Differential pressure resolution0.1pa◆ Test pressure sensorError≤±1%F.S◆ Test pressure range-0.1～0.2MPa/-0.1～0.7MPa/-0.1～1.0MPa◆ Minimum detectable aperture2μm ( for IV bag minimum 5μm)◆ Display method10-inch touch color touch screen◆ VoltageAC100V-240V, 50/60Hz, power ≤200W◆ WeightHost: about 30kg◆ Audit trail>=5 years of storage Multiple event logs, which can be queried according to timeRT 11◆ Authority managementLogin with username and password, level 4 authority, meet FDA 21CFR PART 11 requirements◆ Print functionBuilt in printer◆ History record>=300000 storage◆ Data backupSupport U disk to export data◆ InterfaceEthernet USB RS485(customization)◆ Dimension430*655*420（height1）*330（height2)mm◆ weight51kg
