Product Features
Comply with USP <1207>, ASTM F2338 standards and FDA standards;
Semi-automatic detection, suitable for small batch and multi-variety testing;
Non-destructive non-destructive testing, high accuracy, repeatability, sensitivity;
The instrument is used for vacuum pressure difference detection;
The leak rate can be automatically converted into defect aperture μm;
Database storage of test results for easy quality management;
Database storage of test results for easy quality management;
Touch-type man-machine interface, simple and quick operation: after setting/selecting the test program, only need to manually put in/take out the test sample
Application Area

Pharmaceutical industry

Medical device industry

Food and beverage industry

Environmental protection industry
Technical Parameter
Detailed Parameters
◆ Differential pressure sensor±2kpa, error≤0.5%F.S.◆ Differential pressure resolution0.1pa◆ Test pressure sensorError≤±1%F.S.◆ Test pressure range-0.1～0.2MPa/-0.1～0.7MPa/-0.1～1.0MPa(optional)◆ Minimum detectable aperture2μm◆ Display method10-inch touch color touch screen◆ VoltageAC100V-240V, 50/60Hz, power ≤200W◆ WeightHost: about 30kg◆ Audit trail≥5 years of storage Multiple event logs, which can be queried according to time◆ Authority managementLogin with username and password, level 4 authority◆ Print functionExternal micro printer◆ Data backupSupport U disk to export data◆ Signal output(4-20) mA, RS485, 12V alarm output(customization)◆ Dimension430*655*420（height1）*330（height2） mm◆ Weight32kg
