GENERAL FEATURES

7” colorful touchscreen and smart guide system.

Titration methods, curves and results are displayed in detail.

1 extra burette driver can be installed (optional).

Replaceable burette with high-accuracy (10 ml or 20 ml selectable).

Intelligent operation system provides features including user management, method management, electrode management, titrant management, data management, etc.

Support the following titration modes: DET (dynamic equivalence point titration), MET (monotone equivalence point titration), SET (Preset Endpoint Titration) and MAT (manual titration).

pH calibration and measurement are supported.

Up to 100 user-defined methods and 10 user-defined shortcuts.

Auto calculation with pre-defined formula.

Store up to 200 titration data sets (GLP-compliant).

Data analysis feature helps user review, compare and recalculate results.

Data can be easily transferred to printer via RS-232 communication interface.

Titrator can be controlled by computer via USB or RS-232 communication interface.

Automatic sampler is supported.

INESA Includes

10ml burette

232-01 referenc electrode

213-01 platinum electrode

216-01 silver electrode

217-01 referenc electrode

231-01 pH indicator electrode

T-818-B-6 Temperature probe

Standard pH Buffer Solution powder (pH4.01, 7.00, 10.01)

Specifications

Model

Ti-50

Burette

Repeatability

≤0.2%

Accuracy

10ml Burette: ±0.020ml;

20ml Burette: ±0.030ml

Mechanical Unit

Resolution

1/30000

Measuring Unit

Range

(-2000.00~2000.00) mV, (0.000~20.000)pH

Resolutions

0.01mV,

0.001pH

Accuracy

pH: ±0.002pH

mV: ±0.03% or ±0.2mV

Fluctuation

±0.3mV/3h

Temp. Compensation

Range

(-5.0~105.0) ℃

Resolutions

0.1 ℃

Accuracy

±0.2 ℃

General

Power Supply

AC Adapter, 100-240V AC input, DC24V output

Dimensions

340×400×400 mm

Weight

10 kg

Dimensions (Carton)

540×490×480 mm

Weight (Gross)

12 kg
