GENERAL FEATURES

LCD display screen and smart guide system.
Titration methods, curves and results are displayed in detail.
Replaceable burette with high-accuracy (10 ml or 20 ml selectable).
Support the following titration modes: DET (dynamic equivalence point titration), MET (monotone equivalence point titration), SET (Preset Endpoint Titration) and MAT (manual titration).
pH calibration and measurement are supported.
Store up to 50 titration data sets (GLP-compliant) and 1 latest set of titration curve.
Data can be easily transferred to printer via RS-232 communication interface..
Titrator can be controlled by computer via USB or RS-232 communication interface.
INESA Includes

10ml burette
232-01 referenc electrode
213-01 platinum electrode
216-01 silver electrode
217-01 referenc electrode
231-01 pH indicator electrode
T-818-B-6 Temperature probe
Standard pH Buffer Solution powder (pH4.01, 7.00, 10.01)
Specifications

Model

Ti-40

Burette

Repeatability

≤0.2%

Accuracy

10ml Burette: ±0.025ml,

20ml Burette: ±0.035ml

Mechanical Unit

Resolution

1/14000

Measuring Unit

Range

(-1800.0~1800.0) mV,

(0.00~14.00)pH

Resolutions

0.1mV,

0.01pH

Accuracy

pH: ±0.01pH,

mV: ±0.05%FS

Fluctuation

±0.3mV/3h

Temp. Compensation

Range

(-5.0~105.0) ℃

Resolutions

0.1 ℃

Accuracy

±0.3 ℃

General

Power Supply

AC Adapter, 100-240V AC input, DC24V output

Dimensions

340×400×400 mm

Weight

10 kg

Dimensions (Carton)

540×490×480 mm

Weight (Gross)

12 kg
