GENERAL FEATURES

LCD display screen.
Generator cell with diaphragm.
Selectable units including μg, mg, %, mg/L, g/L, etc.
Settable parameters, including measurement unit, polarization current, generator current, endpoint potential, stop criterion and etc.
Data can be stored and easily transferred to printer via RS-232 communication interface.
Reset feature automatically resumes all settings back to factory default options.
INESA Includes

JB-11 stirrer
Electrolysis electrode
Work electrode
Specifications

Model

KFT-20V

Coulometric Ttration

Range

10ug~20mg

Polarization Current Accuracy

±0.2μA

Working Current

10mA, 20 mA, 50 mA, 100 mA

Working Current Accuracy

±0.5%

Accuracy

± (5%+3) μg

Repeatability

≤3%

General

Power Supply

AC Adapter, 200-240 VAC input

Dimensions

300×235×100 mm

Weight

2 kg
