Features
5‑inch touch screen
Real‑time testing curve
Standard / Fast / Soft test modes
Auto / Manual / Timed stop mode
Silent fast cooling fan
Adaptive input voltage
Test frequency selection
Clock function
Historical test report
Specifications
Model XY‑110ME XY‑105ME XY‑101ME
Capacity 110 g 110 g 110 g
Readability 0.01 g 0.005 g 0.001 g
Sensor Load Cell Load Cell Load Cell
Pan Size Φ100 mm Φ100 mm Φ100 mm
Display 5‑inch touch screen 5‑inch touch screen 5‑inch touch screen
Operation Temp 5–35°C 5–35°C 5–35°C
Heating Source Halogen lamp Halogen lamp Halogen lamp
Temp Sensor PT‑100‑2 PT‑100‑2 PT‑100‑2
Temp Range 40–160°C 40–160°C 40–160°C
Temp Setting 1°C step 1°C step 1°C step
Moisture Range 10.00%–90.00% 5.00%–95.00% 1.00%–100.00%
Moisture Readability 0.10% 0.05% 0.01%
Dry% Readability 0.10% 0.05% 0.01%
Storage 20 sets 20 sets 20 sets
Analysis Curve Real‑time dynamic Real‑time dynamic Real‑time dynamic
Testing Height 30 mm 30 mm 30 mm
Language EN / CN EN / CN EN / CN
Power 220V 50Hz / 110V 60Hz 220V 50Hz / 110V 60Hz 220V 50Hz / 110V 60Hz
Dimension 340×215×170 mm 340×215×170 mm 340×215×170 mm
Packing Size 415×310×255 mm 415×310×255 mm 415×310×255 mm
G.W. / N.W. 4.0 kg / 3.5 kg 4.0 kg / 3.5 kg 4.0 kg / 3.5 kg
