Features
7-inch touch screen
Automatic door / transparent window
High-brightness halogen lamp
Polymer heat-resistant molding
Dual motor drive, double fan design
Temperature control, stainless steel chamber
Real-time dynamic curve, date & time display
Temperature & time setting
Historical data storage
Moisture content percentage display
Connectable to PC and printer
Optional: printer, USB
Specifications
Model XY-100MS XY-100MS (plus) XY-200MS XY-200MS (plus)
Capacity 110g 110g 210g 210g
Readability 0.001g 0.001g 0.001g 0.001g
Operating Temp 5–35°C 5–35°C 5–35°C 5–35°C
Pan Size Φ100mm Φ100mm Φ100mm Φ100mm
Heating Source Halogen lamp Halogen lamp Halogen lamp Halogen lamp
Temp Sensor PT100 PT100 PT100 PT100
Temp Range 40–230°C 40–230°C 40–230°C 40–230°C
Temp Step 1°C 1°C 1°C 1°C
Moisture Range 0.00%–100.00% 0.00%–100.00% 0.00%–100.00% 0.00%–100.00%
Moisture Readability 0.01% 0.01% 0.01% 0.01%
Dry Readability 0.01% 0.01% 0.01% 0.01%
Storage 20 sets 20 sets 20 sets 20 sets
History 20 sets 20 sets 20 sets 20 sets
Display 7-inch touch panel 7-inch touch panel 7-inch touch panel 7-inch touch panel
Interface RS232 (standard), RJ45/USB (optional) RS232 (standard), RJ45/USB (optional) RS232 (standard), RJ45/USB (optional) RS232 (standard), RJ45/USB (optional)
Communication Cable Wireless Cable Wireless
Rechargeable Battery No 10,000mAh No 10,000mAh
Dimensions 415×215×195mm 415×215×195mm 415×215×195mm 415×215×195mm
