Product features
Infrared lamp / HBM sensor
Aluminum shell / Stainless steel chamber
High definition LCD
Temperature / Time set
The percentage of moisture content / Dry residual
Store historical set
Option: Aluminum box / Printer / Grinder
Product specifications
Model XY‑100MW‑IR
Capacity 110g
Readability 0.001g
Operating Temp 5°C‑35°C
Display High definition backlit LCD
Calibration External calibration
Interface RS232
Pan Size 90mm
Packing Size 485340350mm
Gross Weight 7.0kg
Heating Unit Infrared lamp
Temp.Sensor PT100
Temp.Range 40°C‑160°C
Temp.Step 1°C
Moisture Range 0.00%‑100.00%
Moisture Readability 0.01%
Dry Range 100.00%‑0.00%
Dry Readability 0.01%
Temp Setting 40°C‑160°C By 1°C Step
Time Setting 1‑99min By 10s
Number Of Storage 15
Number Of History 5
Heater power 220V ±15% 50Hz / 110V±15% 60Hz / 400W
Balance power Input:220V 50Hz / 110V 60Hz Output:9V
