Product features
Halogen lamp / HBM sensor
Aluminum shell / Stainless steel chamber
LCD(White back light with black font)
Temperature / Time set
The percentage of moisture content / Dry residual
Store historical set
Option: Aluminum box / Printer / Grinder / USB
Model XY‑110MW XY‑105MW XY‑102MW XY‑100MW XY‑100MW‑A
Capacity 110g
Readability 0.01g 0.005g 0.002g 0.001g
Operating Temp 5°C‑35°C
Display Backlit LCD High definition backlit LCD
Calibration External calibration
Interface RS232(Standard) USB(Optional)
Pan Size Φ90mm
Packing Size 485340350mm
Gross Weight 6.8kg
Heating Unit Halogen lamp‑1 Halogen lamp‑2
Temp. Sensor PT100
Temp. Range 40°C‑199°C
Temp. Step 1°C
Moisture Range 0.00%‑100.00% 0.0%‑100.0%
Moisture Readability 0.2% 0.10% 0.04% 0.01%
Dry Range 100.00%‑0.00%
Dry Readability 0.2% 0.10% 0.04% 0.01%
Temp Setting 40°C‑199°C By 1°C Step
Time Setting 1‑99min By 10s
Number Of Storage 15
Heater power 220V±15% 50Hz/110V±15% 60Hz/400W
Balance power Input:220V 50Hz / 110V 60Hz Output:9V
Chamber Height 22mm
