Principle
The air in the air shower enters the static pressure chamber through the primary filter under the action of the fan, and is efficiently discharged to maintain a safe and reliable experimental environment After the air filter is filtered, clean air is sprayed out at high speed from the spray nozzle in the air shower room, with the nozzle angle Adjustable, effectively blowing away dust adhering to the surface of personal characteristics or carried items, and recycling the blown dust into the primary air Filter, this circulation can achieve the purpose of wind drenching.
Product Features
The material of the Air shower is made of SS304, which is integrally formed, with high cost-effectiveness and elegant appearance.
The wind drenching time is adjustable from 0 to 99 seconds
Infrared automatic sensing of wind port opening
The LCD control panel achieves human-machine interaction, voice broadcasting, and timing functions.
Stainless steel air shower nozzle.
The small air shower room is an integral unit, which is more convenient to install and use; The large wind shower room is a split type. Convenient transportation and push
It can be equipped with automatic interlocking, and the material can be customized.
Model FLB-1A FLB-1B FLB-1200 FLB-2400 FLB-3600
Sulted for person Single person/ double sides air blow Single person single side air blow Double person double sides air blow Four person/ double sides air blow Deepen Double sides air blow
Nozzle number 12 6 18 36 48
Jet diameter Φ30mm
Ejection wind speed 15-20m/s
Nozzle mouth materisl Stainless steel
The filter efficiency For particle size of 0.5um dust should be 99.99% or higher flame method (sodium)
Overall dimension 14008002100 12008002100 140012002100 140024002100 140036002100
Working area size 8008001950 8008001960 60012001960 80024001960 80036001950
The power supply AC 220V 50Hz
