Characteristics
• 7″ capacitive touch screen, fully automatically controlled, easy to operate on.
• Elevating type door, which is more convenient to place and fetch the objects from the autoclave.
• The whole procedure from water inlet, pulse vacuum, heat, sterilizing, water outlet, exhausting to vacuum drying, which are all automatically by one-key operation.
• Pulse vacuum, the limit is -0.080Mpa, which ensure the sterilizing more completely.
• Separated steam generator, which is more energy saving by comparing to the normal heating and prevent the sterilizing objects from been oxidized.
• There are several programs loaded in the autoclaves for different requirement of different objects.
• With PT-TT testing port, easy to run the testing.
• Equipped with Germany SARTORIUS Sterile ventilation filter MIDISART 2000 0.20um, which ensure the air is sterile, prevent the contamination.
• Steam-water inner circulation system: no steam discharge, and the environment for sterilizing will be clean and dry.

Technical Data
MODEL

LS-60SV

LS-80SV

LS-100SV

LS-120SV

Technical

Chamber volume

60L

φ396×490mm

80L

φ396×650mm

100L

504×404×502mm

120L

504×404×590mm

The height after rising

1310

1590 1475 1565
Working pressure

0.22Mpa

Working temperature

134℃

Heat average

≤±1℃
Timer range

0-99min
Temperature adjust range

105-134℃
Power

Steam generator：3KW

Dry blanket:2.4KW/AC220V 50HZ

Steam generator：3.6KW

Dry blanket:2.4KW/AC220V 50HZ

Overall dimension(mm） 686×556×913 686×556×1035 840×600×970 840×600×1060
Transport dimension（mm） 789×656×1013 786×656×1135 940×610×1000 940×610×1075
G.W/N.W

210Kg/180Kg
230Kg/200Kg

300Kg/270Kg 325Kg/295Kg
