Use
The product utilizes saturated steam to rapidly and efficiently sterilize articles. It can be used in hospitals, public health centers, health stations,clinics in factories and mines, scientific research institutes, etc, to sterilize medical equipment, surgical dressings, glass utensils, solutions,substrata. It can also be used as cooker in plateau areas and be used to make high quality drinking water in industrial and mining enterprises.

Characteristics
• For 4~6 minutes rapidly sterilizin.
• Digital display of working status, touch type key.
• Witprotection of water lacking.
• Exhaust the h 3 fixed .cycles of sterilizing program and adjustable for user.
• The whole process of water adding, temperaturerising, sterilizing, drying steam discharging controlled automatically.
• Steamwater inner circulation system: no steam discharge, and the environment for sterilizing will be clean and dry.
• Safe cool air automatically.
• Door safety lock system.
• With four stainless steel sterilizing plates.
• The chamber of the sterilizer is made of stainless steel.
• Automatically shut off with beep reminding after sterilization.
• With drying function.

Technical Data
MODEL

TM-XD20D TM-XD24D
Technical Data
Stenilizing chamber volume

20L

φ250×420mm

24L

φ250×520mm

Working pressure

0.22Mpa
Working temperature

134℃
Temperature adjust range

105-134℃
Timer range

0-99min
Heat average

≤±1℃

Power

1.5KW/AC220V.50Hz
Sterilizing plate

340×200×30(3piece) 400×200×30(3piece）
Dimension

480×480×380 580×480×384
Exerior package dimension

700×580×500 800×580×500
G.W/N.W

43/40Kg 50/45Kg
