Intelligent Data Processing
Built-in comprehensive electrical method processing: automatic data handling, imaging, and AI analysis—all in one streamlined workflow to shorten exploration cycles and boost efficiency.
Multi-Terminal Data Sharing
Collected data uploads to the cloud for seamless access. Perform processing, imaging, and AI analysis anytime on mobile APP or PC, enabling rapid anomaly identification and informed decision-making.
Smart Channel Recognition
Automatically detects connected channel count when adding cascade cables—no manual setup required, simplifying operation and enhancing usability.

TECHNICAL PARAMETERS
Versions TPS-ZN50P TPS-ZN150P TPS-ZN300P TPS-ZN500P TPS-ZN1000P TPS-ZN2000P TPS-ZN3000P TPS-ZN5000P
Max Depth (m) ≤50 ≤150 ≤300 ≤500 ≤1000 ≤2000 ≤3000 ≤5000
Scan Interval 5 M
Channel Options One device for 1-60 channels, standard with single channel (MN), optional MN channel extension and TT sensor
Meas. Mode MN/TT
Freq. Range (hz) 0.1-24500 HZ
Filtering FFT Smart
Discrim. 0.01mV±2%
Acq. Time (s) 45s
Connection 19-pin aviation socket (compatible with MN cables and TT sensors), 7-pin aviation socket (charging port / USB transmission integrated interface), wifi 5, bluetooth 4.2
Display 10.1″ IPS high brightness touch screen
Resolution 1024*600
OS Android 13
CPU RK3568
GPU Mali G52
RAM LDDR4/4GB
Storage 32 GB
Core Features Auto analysis, free software upgrade, one device for all channels, segmented depth survey, real-time curve, color contour mapping
Other Features GNSS, optional 4G connection
Battery 6000mAh
Main Device Size 35.3cm*21.6cm*7.6cm
