Use
The product utilizes saturated steam to rapidly and efficiently sterilize articles. It can be used in hospitals, public health centers, health stations,clinics in factories and mines, scientific research institutes, etc, to sterilize medical equipment, surgical dressings, glass utensils, solutions,substrata. It can also be used as cooker in plateau areas and be used to make high quality drinking water in industrial and mining enterprises.

Characteristics
• Fullystainless steel structure.
• Electric or LPG heated.
• Working pressure: 0.l4-0.16Mpa
• Working temperature: 126℃
• Double scale indication pressure gauge.
• Easy to operate, safe and reliable.

Technical Data
MODEL

YX-18LM

YX-24LM

Technical Data
Sterilizing volume

18L

φ280×260mm

24L

φ280×390mm

Working pressure

0.14-0.16Mpa

Working temperature

126℃

Max.Safety pressure

0.165Mpa

Power

AC220V.50HZ/2KW

Transport dimension（mm）

410×410×430

410×410×550

G.W/N.W

16/14Kg

17/15Kg
