Product Features
1.Handwheel type door opening structure
2. Mechanical safety interlock device
3. Computer controlled automatic cycle sterilization program
4. Digital window LCD display working status
5. Temperature can be set arbitrarily (50°C-134°C)
6. Time can be set arbitrarily (0-9999 minutes)
7. Overpressure self release 0.22Mpa
8. Automatic shutdown after buzzer reminder at the end of sterilization
9.All stainless steel material
10 Automatic water inlet and automatic exhaust function
11.Printing of sterilization effect with F0 value
12.With drying function(optional)
Model Volume Power supply Power Dimension of sterilizing chamber Weight Package size
XFH-30CA 30L 220V 3.5KW Φ280×400MM 47KG 510×510×1170MM
XFH-40CA 40L 220V 3.5KW Φ340×425MM 55KG 570×570×1250MM
XFH-50CA 50L 220V 3.5KW Φ340×525MM 58KG 570×570×1300MM
XFH-75CA 75L 380V 4.5KW Φ380×530MM 77KG 630×630×1400MM
XFH-100CA 100L 380V 6.0KW Φ500×560MM 120KG 660×660×1420MM
XFH-150CA 150L 380V 6.0KW Φ500×760MM 130KG 660×660×1220MM
XFH-200CA 200L 380V 8.0KW Φ600×760MM 180KG 790×790×1480MM
