Features
7‑inch touch screen
Large capacity & high precision
Large stainless steel pan
AC/DC power supply
Date/time setting
Tare, counting, percentage, density
Check weighing, net/gross, accumulation
Unit conversion (g/ct/oz…)
Overload alarm
Connect PC & printer
Self‑adhesive label printing
Expandable: remote display
Applications
Platform scale, industrial weighing
Specifications
Model XY‑INA XY‑INB Custom
Capacity 10–150kg 3–30kg Custom
Readability 1g/2g/5g/10g 0.1g/0.2g/0.5g Custom
Operating Temp 5–35°C 5–35°C 5–35°C
Repeatability ±3d ±3d ±3d
Linearity ±3d ±3d ±3d
Stable Time ≤3s ≤3s ≤3s
Pan Size 220×300 / 300×400 / 400×500mm 220×300 / 300×400 / 400×500mm Custom
Display 7‑inch touch screen 7‑inch touch screen 7‑inch touch screen
Interface RS232/USB, Excel export RS232/USB, Excel export RS232/USB
Internal Calibration Optional Optional Optional
Functions Counting / Check weighing / Percentage / Density Counting / Check weighing / Percentage / Density Custom
Power 220V 50Hz / 110V 60Hz Output 9V 220V 50Hz / 110V 60Hz Output 9V Custom
Battery 10000mAh Li‑battery 10000mAh Li‑battery Optional
Printer Label printing supported Label printing supported Optional
Packing Size 415×165×430mm 415×165×430mm Custom
