Features
Appearance & utility model patents
7‑inch touch screen
Large capacity & high precision
Large stainless steel pan
AC/DC power supply
Date/time setting, under weighing
Tare, counting, check weighing, percentage, density
Net/gross, accumulation
Unit conversion (g/ct/oz…)
Overload alarm
Connect PC & printer
Options: label printer, external display, scanning gun, internal calibration (XY10MTA, XY10MTB)
Applications
Factory workshop, warehouse, logistics, batching site
Specifications
Model XY10MTA XY20MTA XY30MTA XY10MTB XY20MTB XY30MTB
Capacity 10kg 20kg 30kg 10kg 20kg 30kg
Readability 1g 0.1g 0.1g 1g 0.1g 0.1g
Operating Temp 5–35°C 5–35°C 5–35°C 5–35°C 5–35°C 5–35°C
Repeatability ±3d ±3d ±3d ±3d ±3d ±3d
Linearity ±3d ±3d ±3d ±3d ±3d ±3d
Stable Time ≤2s ≤2s ≤2s ≤2s ≤2s ≤2s
Pan Size 305×230mm 305×230mm 305×230mm 305×230mm 305×230mm 305×230mm
Display 7‑inch touch screen 7‑inch touch screen 7‑inch touch screen 7‑inch touch screen 7‑inch touch screen 7‑inch touch screen
Interface RS232/RJ45/USB RS232/RJ45/USB RS232/RJ45/USB RS232/RJ45/USB RS232/RJ45/USB RS232/RJ45/USB
Internal Calibration Optional Optional Optional Optional Optional Optional
Functions Counting / Check weighing / Percentage / Density Counting / Check weighing / Percentage / Density Counting / Check weighing / Percentage / Density Counting / Check weighing / Percentage / Density Counting / Check weighing / Percentage / Density Counting / Check weighing / Percentage / Density
Power Input 100–240V 50/60Hz Output 9V Input 100–240V 50/60Hz Output 9V Input 100–240V 50/60Hz Output 9V Input 100–240V 50/60Hz Output 9V Input 100–240V 50/60Hz Output 9V Input 100–240V 50/60Hz Output 9V
Battery 6V/4AH rechargeable 6V/4AH rechargeable 6V/4AH rechargeable 6V/4AH rechargeable 6V/4AH rechargeable 6V/4AH rechargeable
Dimensions 395×320×118mm 395×320×118mm 395×320×118mm 395×320×118mm 395×320×118mm 395×320×118mm
Packing Size 460×365×210mm 460×365×210mm 460×365×210mm 460×365×210mm 460×365×210mm 460×365×210mm
Gross Weight 7.5kg 7.5kg 7.5kg 7.5kg 7.5kg 7.5kg
