Intelligent and Efficient with Flexible Configuration
Supports free switching between 1–60 channels. For simple areas, single-channel mode enables rapid surveying; for complex or high-precision scenarios (such as guaranteeing a water-rich well, or “water guarantee” projects), it can be easily upgraded to 12/24/36/48/60 channels, perfectly balancing efficiency and accuracy.
Advanced Technology for Reliable Data
Utilizing natural electromagnetic fields as the source and multi-channel synchronous measurement technology, it overcomes the randomness of traditional MT field sources, obtaining stable, highly repeatable data on underground electrical structures.
AI-Powered Real-Time Decision Making
Equipped with proprietary intelligent software and AI algorithms, it achieves real-time imaging of geological structures, precise prediction of groundwater distribution and quality, and assists field personnel in optimizing drilling strategies on the spot—critical for successful water well projects.
Strong Adaptability and Easy Operation
Supports optional sensor probes, ideal for complex terrains where electrodes are difficult to insert. Significantly reduces manual processing time and error rates, improving the overall efficiency and success rate of groundwater exploration and well drilling.
TECHNICAL PARAMETERS
Versions TPS-ADMT-200ZN TPS-ADMT-400ZN TPS-ADMT-800ZN
Max Depth (m) ≤200 ≤400 ≤800
Scan Interval 10 M
Channel Options One device for 1-60 channels, standard with single channel (MN), optional MN channel extension and TT sensor
Meas. Mode MN/TT
Freq. Range (hz) 0.1-6500 HZ
Filtering FFT Smart
Discrim. 0.01mV±2%
Acq. Time (s) 15s
Connection Six-pin aviation socket (compatible with MN cables and TT sensors), charging port / USB transmission integrated interface, wifi 5, bluetooth 4.2
Display 7 “IPS high brightness touch screen
Resolution 1024*600
OS Android 13
CPU RK3568
GPU Mali G52
RAM LDDR4/4GB
Storage 32 GB
Core Features Auto analysis, free software upgrade, one device for all channels, segmented depth survey, real-time curve, color contour mapping
Other Features GNSS, optional 4G connection
Battery 6000mAh
Main Device Size 24.6cm*17.4cm*8.2cm
