Main Applications:

Groundwater Exploration: Finds ground water with better detail and accuracy than standard detectors, offering more features.

Mineral Exploration: Uses electromagnetic methods to map ore bodies and estimate mineral reserves in mining areas.
MAIN MODELS
AND TECHNICAL PARAMETERS
Versions TPS-ADMT-200AX TPS-ADMT-500AX
Max Depth (m) ≤200 ≤500
Channel Input Single channel
Channel Options 1
Depth Options 100-200 m 100-500 m
Scan Interval 10-100 m
Connection Serial port, WiFi, Bluetooth 4.0, USB (optional 4G transmitting）
Display 7 inch, IPS wide angle, 178° visual touch screen
OS Android 6.0.1 / Android 13
CPU ARM Cortex-A7 8-core CPU 2.0Hz / RK3568
GPU OpenGL ES 2.0 / Mali G52
Core Features selectable depths, real-time 2D/3D imaging, detachable battery
Meas. Mode MN/TT
Freq. Range (Hz) 1-8K
Filtering Preset/intelligent filtering with analog and digital filters, plus 1-16x stacking
Discrim. 0.1mV±2%
Acq. Time (s) 100-360
Battery 700mA/H
Main Device Weight 1.6kg
